Gentec Dual Flowmeter Regulator 196AR-60

Gentec Premium Dual Flow Meter. Victor Style High-Quality Premium Series Flowmeter/Regulator Engineered to Deliver Precise Control of Shield Gases.Gentec196AR60 flowmeter regulators are designed for MIG & TIG applications to provide accurate regulation of gas flow. They are also ideal for commercial industrial and laboratorial applications. Body machined from class “A”brass. Single -stage construction.Accurately regulate the flow of welding gases to two separate welding processes from a single gas cylinder. Use with a torch and a backup purge bar, secondary shield nozzle, trail shield or flooding cup.

High-Quality Dual Flowmeter/Regulator

Features

• Regulator is preset at 50PSIG

• Body machined from class A brass

• Single-stage construction

• Monitoring two separate gas flow settings at the same time

• 2 gauge and two 195FM flowmeters

• Polycarbonate flow tube and hood are impact resistant for maximum durability and service life durability and service life

• Calibrated for argon, helium and 75% argon / 25% CO2mixed gases

• Flowmeter is backpressure compensated to ensure accurate readings when line restrictions are present

• Sintered bronze inlet filter

• Weight: 4 lbs. 10 oz.

• Conforms to CGA E-4 Standard for Gas Pressure Regulators

Includes

• Body machined from class “A” brass bar stock.

• Single Stage Construction.

• Monitor two separate processes at the same time.

• Polycarbonate flow tube and outer cover are impact resistant for maximum durability.

• Conforms to CGA E-4 standard for gas pressure regulators.

• Gas Service: Argon, AR/CO2 Mix.

• Outlet Pressure (PSI): 50.

• Inlet Connection: CGA580.

• Outlet Connection: 5/8″ – 18RH(F).
