Kurt 6 HDL AngLock Manual Vise (Metric) with Aluminum Jaw Kit – HDLM6AL

Kurt 6″ HDL AngLock Manual Vise (Metric)
with Aluminum Jaw Kit – HDLM6AL

High Density Vise

The HDLM6AL is a 6 inch wide High Density double station vise. This vise features quick change machinable aluminum jaws with Metric fasteners.

Kurt Workholding’s 4″ and 6″ HDL manual vises are high density vises with English threads and are compact to allow for maximum workholding across a range of machining centers. Our high-density HDL manual vises provide versatility with a stationary center jaw block and double clamping stations for use with same or dissimilar sized parts.

Benefits of using a manual vise with two clamping stations are reduced tool change time and better spindle utilization. These high density manual vises also help neutralize bending pressure placed against the center of the vise. Our HDL manual vises are suitable for work involving high precision machining, and for work with small or large parts.

The manually actuated HDL Vises are high-density, doublelock, clusterlock, heavy-duty systems with multiple clamping stations and machinable jaws. They feature quick change AngLock jaws in Hard Jaw, Machinable aluminum and Cast steel configurations for multiple applications. HD Vises are designed to provide maximum workpiece immobility and dampen cutter induced vibration.

The HDL AngLock Vises are high density long vises with two clamping stations. They provide repeatable clamping to 0.0002″ and combine high density with heavy duty features. Designed on a rugged 80,000 PSI ductile iron body with steel components, both models provide strength, rigidity and long term accuracy while absorbing machining vibration.

Features:

• Two clamping stations repeatable clamping to 0.0002″.
• Maximum clamping force of 5,870lbs for 4″ vises and 7,460lbs for 6″ vises
• Pre-loading front and back jaws that hold your workpieces in place as you adjust the jaws
• Multiple jaw options allow for complete customization
• Constructed of rugged, 80,000 PSI ductile iron body with steel components
• Full 3 and 4 inch opening in each station with standard hard jaw system.
• Jaws are indexable 180 degrees.
• Manual and hydraulic models available.
• Fast easy conversion between manual and hydraulic models. Part #HDHLM4-3-SA-KIT (4 inch) & #HDHLM6-3-SA-KIT (6 inch)
• Maximizes the number of parts in the work envelope.
• Adjustable pre-load feature allows you to minimize pre-load range thus reducing the turns of the handle to open or close the vise (manual version).
• Holding block features the ability to clamp same or dissimilar sized parts and provides pre loading ability in the front or back jaw (manual version).
• Lifetime Iron Clad Warranty.
• Bed height tolerance 0.001″.
• Patented
• Optional clutchless design available for lower clamp force applications. Call factory.

HDL Manual Vise Jaw Options:

Kurt workholding 4″ and 6″ HDL manual vises are available with a variety of jaw types that can easily be changed out, allowing you to customize your high-density vise based on your application requirements. Our vises have a quick-change jaw feature with fewer components for faster changeovers, saving you time. HDL manual vise jaw options include:

• Hard jaws
• Machinable aluminum jaws (in standard or tall height)
• Machinable ductile iron jaws
• Aluminum fixture plate

Machinery Types for HDL Manual Vises:

Kurt Workholding’s HDL 4″ and 4″ manual vises are suitable for a variety of machining applications.

• CNC Horizontal and Vertical Machining
• Manual Mills
• Pallet Changes for VMC’s

Dimensional Data:

Inch
mm

A
3.125
79.375

B
6.000
152.400

C
21.000
533.400

D
10.192
258.877

E
3.250
82.550

F
21.250
539.750

G
10.625
269.875

H
1.450
36.830

J
0.860
21.844

K
2.500
63.500

L
5.000
127.000

M
5.000
127.000

N
1.728
43.891

O
6.000
152.400

P
4.000
101.600

Q
3.312
84.125

R
0.969
24.613

S
0.522
13.259

T
0.750
19.050

T
EXT HEX
EXT HEX

U
0.438
11.125

V
2.125
53.975

W
3.875
98.425

X
M10x1.5
M10x1.5

Z
0.156
3.962

AA
0.625
15.875

AA
INT HEX
INT HEX

BB
0.438
11.125

CC
1.125
28.575

DD
3.125
79.375

EE
M8x1.25
M8x1.25

FF
1.000
25.400

GG
0.984
25.000

HH
2.9528
75.000

JJ
5.000
127.000

KK
7.000
177.800

LL
6.890
175.000

MM
2.000
50.800

NN
1.969
50.000

OO
M12 SHCS
M12 SHCS

PP
1/2 SCHS
1/2 SCHS

QQ
0.625
15.875

RR
0.6299
16.000

Estimated Shipping
Weight of Vise Body
Only
71 Lbs
32.21 Kgs

Clamping Force Pounds:

Torque Ft. Lbs.
HDLM6

10
1540

20
2520

30
3350

40
4310

50
5750

60
6860

70
7460
