Light, precise, user-friendly.
The all-new upgraded KGS 216 M Mitre Saw replaces the laser line with a Precision Cut Line which provides a precise shadow cutting line without re-adjustment thanks to cleverly positioned LED.
- Crosscut and mitre saw of the mobile M-class with sliding function light, precise, and user-friendly
- Large cutting capacity thanks to sliding function for wide work pieces
- Turntable with fast, precise setting of common angles using stop points
- Saw blade inclination from -2 to 47, therefore also suited for undercuts
- Robust die-cast aluminium design for the highest demands
- Effective dust extraction via integrated dust scoop
- Soft start for long service life of motor and drive
- Extendable table width extensions, also removable to put underneath extremely long workpieces.
- Quick-action clamp for secure fixing of the workpiece from the top or front
- Depth guide for easy creation of grooves
- All scales and operating elements are visible from the working position and can be operated intuitively
- The METABO KGS 216 M Mitre Saw 613216000 has an ergonomic handle area for carrying with one or two hands
Included
- Saw blade precision cut wood classic, 21630, Z40
- 2 Table length extensions
- Length Guide
- Material clamp
- Tool for saw blade change
- Cable winder
- Chip Collection Bag
Specifications
| Dimensions |
710 x 476 x 512mm
|
| Support surface |
345 x 730mm
|
| Maximum cutting width 90/45 |
305 / 215mm
|
| Maximum cutting depth at 90/45 |
70 / 40mm
|
| Cutting capacity 90/90 |
305 x 70mm
|
| Cutting capacity 45/45 |
215 x 40mm
|
| Turntable setting left/right |
50 / 50
|
| Saw blade tilt left/right |
47 / 2
|
| Saw blade |
216 x 30mm
|
| Rated input power |
1200W
|
| Rated input power S1 100% |
1200W
|
| Rated input power S6 20% |
1500W
|
| No-load speed |
5000rpm
|
| Speed at rated load |
3750rpm
|
| Cutting speed |
57m/s
|
| Weight |
13.4kg
|
| Cable length |
2m
|
