Niagara Cutter 3/4, 3-1/4 LOC, 3/4 Shank Diam, 6 OAL, 2 Flute, Solid Carbide Square End Mill Single End, Uncoated, Spiral Flute, 45 Helix, Centercutting, Right Hand Cut, Right Hand Flute, Series A245 17002987 – 70219043

Niagara Cutter 3/4″, 3-1/4″ LOC, 3/4″ Shank Diam, 6″ OAL, 2 Flute, Solid Carbide Square End Mill Single End, Uncoated, Spiral Flute, 45 Helix, Centercutting, Right Hand Cut, Right Hand Flute, Series A245

Manufacturer Part #: 17002987

S/N: 70219043

UNSPSC: 27112803

(Minimum Order Quantity=1, Package Quantity=1)

Specifications:

Mill Diameter (Decimal Inch)
0.7500
Mill Diameter (Inch)
3/4
Number Of Flutes
2
End Mill Material
Solid Carbide
Length of Cut (Decimal Inch)
3.2500
Length of Cut (Inch)
3-1/4
Shank Diameter (Inch)
3/4
Shank Diameter (Decimal Inch)
0.7500
Overall Length (Decimal Inch)
6.0000
Overall Length (Inch)
6
Single Or Double End
Single
Coating/Finish Family
Bright/Uncoated
Centercutting
Yes
Cutting Direction
Right Hand
Flute Direction
Right Hand
Extended Reach
No
Coolant Through
No
Helix Angle
45
Primary Workpiece Material
Aluminum & Non-Ferrous
Primary Workpiece Material Code
N
Coating/Finish
Bright/Uncoated
Variable Helix
No
Variable Index
No
Chipbreaker
No
Flute Type
Spiral
Shank Type
Straight-Cylindrical
Material Grade
Micrograin
Length Type
Long
Length Of Cut Range (Decimal Inch)
2.0000+
Mill Diameter Tolerance
+0.000 to -0.002 in
Shank Diameter Tolerance
-0.0001/-0.0004 in
Overall Length Tolerance
+0.0600/-0.0600 in
TIR Maximum (Decimal Inch)
0.0005
Series
A245
System Of Measurement
Fractional Inch
UNSPSC Code
27112803
