Model
05125N
Cut Type
Second Cut
File Length
12″
File Width
1-1/8″
File Thickness
11/32″
Nicholson Half Round File 05125N, Second Cut, 12″ Length
12″ Long, Second Cut, Half Round American-Pattern File
Double Cut, 0.3438″ Overall Thickness, Tang
Features:
- American Pattern
- Used by engineers and machinists for rapid removal of metal
- The cross section, which is rounded on one side and flat on the other, allows file to be used effectively on convex and concave surfaces.
- Tapered toward the points in width and thickness
- Half round files are used for rounding out holes and filing concave, convex and flat surfaces. These files are rounded on one side and flat on the other.
- Single cut files consist of one set of parallel, diagonal teeth extended across the face of the file. They are used for sharpening or to produce a smooth finish. Double cut files consist of two sets of teeth crisscrossing each other at opposite angles. They are used for heavy stock removal.
- Second cut files have a medium coarseness. They are used for intermediate smoothing and finishing work.
Specifications:
Manufacturer Part #
05125N
File Type
Half Round
Length (Inch)
12
Coarseness/Cut
Second Cut
Cut Type
Double
Overall Width/Diameter (Inch)
1-1/8
Overall Thickness (Inch)
11/32
Tang or Handle
Tang
Flexible
No
Length of Cut (Inch)
12
