Precise Back Plate Lathe Chuck Adapter Plate for Zero-Set Lathe Chuck, 6 D1-4 – 560-040

Precise Back Plate Lathe Chuck Adapter Plate for Zero-Set Lathe Chuck, 6″ D1-4

The back plate is fully machined but still need secondary operation to fit with Zero-Set lathe scroll chucks, both 3 jaws or 6 jaws. The back plate has 6 drill & tap holes (Bolt Circle Dia.: 5.343”) and a hub that fits the recessed of the lathe chuck.

Features:

• For Zero Set lathe chuck
• D-MOUNT Cast-iron camlock adapter plates with thru hole
• Complete finished, not required to do any machining or drilling or tapping on the back plate

Specifications:

Lathe Chuck Category
Back Plates Camlock Mounting

back plate diameter
6

Spindle Nose Type
D Series

no. of studs
3

stud diameter
5/8

compatible chuck diameter
6

mounting
D1-4

for use with Precise 3-Jaw & 6-Jaw Zero-Set Fine Adjustment Self-Centering Scroll Chucks
