TMX Lathe Chuck, 4-Jaw, 5in – 3-855-0501P

Chuck Diameter

5″

TMX Lathe Chuck, 4-Jaw, 5in
3-855-0501P

4-Jaw (Solid) Independent Forged Steel Body Chuck
Plain Back 5in
TMX by Toolmex
MADE IN POLAND

Features:

• Four-jaw standard duty independent Lathe Chucks with solid reversible jaws, spheroidal graphite iron body.

• The jaws are made of high quality carbon steel and hardened. Thrust bearings and operating screws are case hardened steel.

• These chucks feature jaws that are individually adjustable, allow firm gripping of odd shaped work and the jaws allow a square component to be perfectly centered to the chuck while achieving maximum gripping force.

Technical Data:

Selling Unit

EA

Chuck Type

Independent

Chuck Size
in
5

Body Material

Forged Steel

Number of Jaws

4

Jaw Type

Solid

Weight
lb
10.7

Mount Type

Front

RPM max
RPM
3500

D
in
5

B
in
2.748

C
in
0.0984

E
in
1.0236

F
in
2.126

H
in
1.6929

H2
in
0.7874

S

4xM8
