SPI 3-Point Hole-Mike Inside Micrometer, 10.000 – 11.000 – 10-760-7

Range

10.000 – 11.000″

Graduation

0.0002″

Measuring Depth

5.51″

Accuracy

0.0008″

SPI 3-Point Hole-Mike Inside Micrometer
10.000 – 11.000″ -10-760-7

10 to 11″, 5.51″ Gage Depth, Mechanical Inside Hole Micrometer

0.0002″ Graduation, 0.0008″ Accuracy, Ratchet Stop Thimble

Features:

• Three point internal micrometer for precise direct measurement of bore diameters
• Self aligning and self centering
• Carbide measuring anvils
• Suitable to measure to within.050″ of bottom of blind hole, up to 4″ capacity
• Feelers taper toward the back for positive reading of the front edge
• Ratchet stop provides uniform measuring pressure and assures highest reading accuracy
• In lieu of Setting Rings, Setting Frames are provided for diameter ranges above 7″ dia.

Specifications:

Item Number
10-760-7

Type
Hole

Minimum Measurement (Decimal Inch)
10.0000

Maximum Measurement (Decimal Inch)
11.0000

Graduation (Decimal Inch)
0.0002

Thimble Type
Ratchet Stop

Accuracy (Decimal Inch)
0.000800

Gage Depth (Decimal Inch)
5.5100

Number of Contact Points
3

Number of Extension Rods
0

Number of Setting Rings Included
0

Setting Ring Diameter (Decimal Inch)
11.0000

Digital Counter
No
