Suburban Rotary Vane Vacuum Pump, 1/4 HP Single Phase VCP-14-MM – 77-176-6

Suburban Rotary Vane Vacuum Pump, 1/4 HP Single Phase VCP-14-MM

1/4 HP, 110-115/208-230V, 50-60 Hz, 1 Phase

• All models are the oilless, motor-mount, rotary vane design for maximum performance with minimum upkeep.
• Each unit has internal mufflers and filters. The filters were specifically designed to be easily removed and replaced.
• The pumps have built-in thermal overload protection.
• Each model includes a support base, the proper fittings and six feet of reinforced hose.

NOTE: Because electric motors are dual frequency, multi-voltage AC for worldwide applications, they are supplied without an electric cord, ready to be wired to user specifications.

Specifications:

Model
VCP-14-MM

Electric Motor
1/4 HP, 110-115/208-230V, 50-60 Hz, 1 Phase

CFM Free Air – at 0″ Hg
4.5

CFM Free Air – at 10″ Hg
2.6

CFM Free Air – at 20″ Hg
1.0

Maximum Vacuum
10 PSI

Weight
32 lbs.

For use with Suburban Tool Sine System Bolt-On Vacuum Chucks
